90° A/C Outlet

Details

Fits the mechanical fuel pump on a Lycoming engine. Beware! The pump does not take the tapered thread common to most AN fittings!

Also available in, straight( Straight A/C Outlet ) and 45 degree fittings( 45° A/C Outlet ), all with 3/8" AN flare outlets that mate with aircraft hoses.

Also available is a tee fitting( 90° Fitting Tapped with additional 1/8"NPT Port ), w/tapped 1/8" pipe thread port for fuel pressure fitting.

More Information

More Information
Aircraft	RV-10, RV-12, RV-12iS, RV-14, RV-14A, RV-3, RV-4, RV-6, RV-6A, RV-7, RV-7A, RV-8, RV-8A, RV-9, RV-9A

Specs

Used in these kits

RV-3, RV-4, RV-6, RV-6A, RV-7, RV-7A, RV-8, RV-8A, RV-9, RV-9A, RV-10, RV-12, RV-12iS, RV-14, RV-14A

Cross Reference Part Numbers

6801-06-06-NWO

Fits Tube Outer Diameter

3/8

Material

Steel

Type

90 Elbow
